400 Series Stainless Steel Bright Bar
Premium quality stainless steel bright bars available in grades 410, 410S, 420, 430, 431, and 440A/B/C, manufactured from hot rolled plain bars and wire rods.
Product Specifications
| Products |
Stainless Steel Bright Bar |
| Standard |
ASTM GB DIN EN |
| Diameter |
3-100 mm |
| Length |
6m /pcs or cutting as request |
| Finishing |
black bar / Bright Bar |
| Main Grades |
201, 301, 303Cu, 304, 304L, 309S, 310S, 316L, 316Ti, 317L, 318, 321, 347, 410, 420, 430, 431, 440a/b/c, 904L, 2205, 2507, Hastelloy C276, C4, C22, Inconel 600, 625, Incoloy 800, 825, 825H, etc. |
| Service |
Cutting, surface polishing, heat treatment |
| Brand |
Walsin, BAOSTEEL, TISCO, QINGSHAN |
Material Description
Our stainless steel bright bars feature smooth, bright surfaces with accurate dimensional tolerances and improved mechanical properties. These superior products offer significant design advantages and are widely used in pumps, fasteners, automobile components, furniture products, and cutlery products. All engine components such as nuts, bolts, and shafts in the automobile industry are manufactured from special grades of our bright bars.
Product Categories
Cold Drawn & Polished Round Bars
| Size Range (DIA) |
1.8MM TO 55.56MM |
| Tolerance |
h8, h9, h10, h11 |
| Grades |
201, 201 Ni 3, 202, 204Cu, 303, 304, 304L, 316, 316L, 409, 410, 416, 420, 430, 430L, 430F |
Peeled & Polished Round Bars
| Size Range (DIA) |
14MM TO 140MM |
| Tolerance |
h9, h10, h11, k10, k12, k13 |
| Grades |
303, 304, 304L, 316, 316L, 410, 416, 420, 430, 430L, 430F, 431, 2205, 2507, 904L |
Forged, Rough Turned Round Bars
| Size Range (DIA) |
150MM TO 400MM |
| Tolerance |
0mm/+3mm (-0 "/+0.12") |
| Grades |
304, 304L, 316, 316L, 410, 416, 420, 431, 310S, 2205, 2507, 904L |
Standard Specifications
ASTM / A276
This specification encompasses cold-finished or hot-finished bars, including rounds, squares, and hexagons, and hot-rolled or extruded shapes, such as angles, tees, and channels in the more commonly used types of stainless steels.
ASTM / A479
This specification includes cold and hot finished stainless steel bars, including rounds, squares, and hexagons, and hot-rolled or extruded shapes such as angles, tees, and channels.
ASTM / A484
This specification includes wrought stainless steel bars, shapes, forgings, and billets or other semi-finished materials, except wire, for forging. The materials are available in four types of conditions.
ASTM / A582
This specification includes cold or hot finished bars, which are suitable for machining processes. This specification includes rounds, squares, and hexagons, from common types of stainless free-machining steels.
ASTM / B473
This specification includes nickel alloy bar & wire, which can be produced in a solution-annealed condition, stabilized-annealed condition, or annealed condition.
